16-7
dummyheaddummyhead
GEAR CASE (STANDARD ROTATION)
ANODE METAL/WATER SCREEN
REMOVAL/INSTALLATION
SELF-LOCKING NUT (6 mm)
SELF-LOCKING NUT (5 mm)
1 N·m (0.1 kgf·m, 0.7 lbf·ft)
WATER SCREEN SCREW (5 x 55 mm)
ANODE METAL (2)
WATER SCREEN (2)
BOLT (6 x 55 mm)
O-RING
6.5 N·m (0.66 kgf·m, 4.8 lbf·ft)
GEAR OIL CHECK BOLT
6.5 N·m (0.66 kgf·m, 4.8 lbf·ft)
GEAR OIL DRAIN PLUG BOLT
O-RING
