2.2. Setting up tanks
8
2.2.1. Granular tank settings
Drive Drive Settings Control Settings
Electric Motor selection
Pulses/rev
Min motor RPM
Max motor RPM
Gear ratio
Soft start
Shaft sensor
Shaft pulses/rev
Actuator Encoder teeth
Clutch
Style
Proportional valve Gear ratio
Encoder pulses/rev
Min shaft RPM
Max shaft RPM
Tank clutch
Shaft sensor
Shaft pulses/rev
Add dither
Soft start
Soft stop
Dump valve
Min PWM
Max PWM
Controller response
Monitor Gear ratio
Encoder pulses/rev
Tank clutch
Shaft sensor
Shaft pulses/rev
Electric drive
An electric motor electrically drives the metering or discharge unit.
Rate is controlled by controlling the RPM of the unit via varying the
PWM or current supplied to the motor.
