Chapter 2 – Seeder Settings
21
2.5. Setting up wheel factor
The wheel factor defines how far the implement travels per pulse from
the wheel sensor. A wheel fitted with four magnets, with a
circumference of one meter, will travel 0.25 meters per pulse.
2.5.1. Manual entry of wheel factor
1.
Select Seeder Settings Menu / Wheel Calibration Settings
.
l
Wheel factor:Enter a value in meters/pulse and confirm
Note: Record this value for future use. Use the table on page 87 to
record the wheel factor.
l Num magnets: The number of magnets fitted to the implement
wheel.
2.5.2. Automatic calibration of wheel factor
1.
Select Seeder Settings Menu / Wheel Calibration Settings
.
2.
Select from the top right corner.
