Receiver Specifications
P/N 7010-0681
A-3
Storage temperature -40 C° to +75 C° with batteries
Humidity 95%
Power
Internal battery Li-ion, 4000 mAh, 7.4 V
Not removable
Battery size 132 x 35 x 18 (mm)
Battery weight 165 g (1 battery)
Number of built-in
batteries
2 batteries
Operating time With TX mode ON (1W):
~6 hours
With RX mode ON:
~TBD
With radio in STANDBY mode:
~13 hours
With radio OFF:
~16 hours
External power 1 port
Input voltage 6 to 28 V DC (for work)
9 to 28 V DC (for charge battery)
Minimum Charge Current <=2 Amp
Consumption ~10 W in TX mode (1W)
~TBD W in RX mode
~4.6 W in Standby mode
~3.6 W with radio off
On-board Backup battery for timekeeping and almanac data storage;
10 years minimum operation
I/O
Communication
Ports
Up to four high speed RS232 serial ports, a USB port, and
an internal Bluetooth communication port.
Connectors Modem Antenna, PWR, USB
Table A-1. Receiver Specifications (Continued)
