Topcon HiPer Pro - USB Connector

Specifications
HiPer Pro Operator’s Manual
A-12
USB Connector
The USB connector is a sealed receptacle, 5 pin TPS cable connector
(Figure A-3).
Figure A-3. USB Connector for GGD Options
Table A-8 gives the USB connector specifications.
Table A-8. USB Specifications
Number Signal Name Dir Details
1 Not used
2 USB_PWR P Bus power input
3 GND - Ground
4 USB D+ I/O Data plus
5 USB D- I/O Data minus
