Topcon HiPer Pro - Setting the Radio Link

Configuration
HiPer Pro Operator’s Manual
2-28
Setting the Radio Link
The Base Station and Rover require the following same radio
configuration settings to properly communicate:
• Current frequency
• Signal Threshold Level
• Free Channel Scan
NOTICE
NOTICE
The default settings for radio configuration should be
sufficient for most jobsites. Changing these settings can
affect the operation of the radio modem and
communication between receivers.
The Radio Link tab (Figure 2-20 on page 2-29) has settings for
establishing a link between the Base Station and Rover. Use the
following table to determine the settings for the Base and Rover
receivers (Table 2-3).
Table 2-3. Radio Link Tab Settings
Radio Link Settings
Optimal Scenario
(~100m between
receivers)
Maximum Distance
Scenario (~3–4km
between receivers)
Current Frequency Base and Rover on same
frequency.
Base and Rover on same
frequency.
Output Power Base at 10.
Rover at 10.
Base at 1000.
Rover at 10.
Signal Threshold Power Base and Rover at -112. Base and Rover at -112.
Free Channel Scan Base and Rover on same
setting.
Base and Rover on same
setting.
