HiPer Pro Operator’s Manual
3-10
Real-time Kinematic Survey
Real-time kinematic (RTK) is a differential GPS process where
information, such as differential corrections, is transmitted in real-
time from a Base station to one or more Rover stations.
Set up an RTK Base Station
To configure an RTK Base station using PC-CDU, take the following
steps:
1. Set up the Base station receiver’s antenna as described in
“Receiver Setup” on page 3-1.
2. Press the power key on the receiver.
3. Check the STAT light for tracked satellites.
4. Connect your receiver and computer. See “Connecting the
Receiver and a Computer” on page 2-10 for this procedure.
5. Click ConfigurationReceiver.
6. Click Set all parameters to defaults located at the bottom of the
dialog box (Figure 3-6).
Figure 3-6. Set All Parameters to Defaults
7. On the Receiver Configuration screen, click the MINTER tab and
specify the desired settings. Refer to the PC-CDU User’s Manual
for more information.
