Topcon HiPer Pro - Battery LED

Using the MINTER
P/N 7010-0681
4-7
Battery LED
The color of the BATT LED indicates the level of internal battery
charge in the HiPer Pro:
• Green – indicates greater than 85% charge.
• Orange – indicates an intermediate charge.
• Red – indicates less than 15% charge.
The pattern of blinks of the BATT LED also indicates the source of
power.
• Solid light – an external power supply is used and the batteries are
not being charged.
• Blinking once a second – the batteries are being charged.
• Blinking once every five seconds – the HiPer Pro uses the internal
batteries for power.
• Not blinking – the receiver is in Zero Power Mode or the internal
batteries are completely discharged and no external power is
connected.
NOTICE
NOTICE
When the internal batteries have completely discharged
and no external power is connected, the receiver will go
into Zero Power Mode to prevent the batteries from over
discharging.
