Topcon HiPer Pro - GPS Board Details

Specifications
HiPer Pro Operator’s Manual
A-6
GPS Board Details
Table A-2 lists the GPS board’s general specifications.
Survey Modes
Base or Rover Static
Kinematic (Stop and Go)
RTK (Real-time Kinematic)
DGPS (Differential GPS)
WASS/EGNOS DGPS
Survey Accuracy
Static, Fast Static For L1+L2 – H: 3mm + 0.5ppm (x baseline length);
V: 5mm + 0.5ppm (x baseline length)
Kinematic, RTK
For L1+ L2 – H: 10mm + 1.0ppm (x baseline length)
;
V: 15mm + 1.0ppm (x baseline length)
DGPS <1m
Cold Start
Warm Start
Reacquisition
< 60 sec
< 10 sec
< 1 sec
Table A-2. GPS Board Specifications
Receiver Type (set by activating the proper OAF)
Euro-112T
(HGGDT)
G: GPS L1
GD: GPS L1/L2
GG: GPS/GLONASS L1
GGD: GPS/GLONASS L1/L2
Tracking Specifications
Standard Channels 20 channels (G, GG, GD, GGD)
L1 GPS, L1/L2 GPS, L1 GLONASS, L1 GPS + L1
GLONASS, WAAS/EGNOS, PCode and Carrier
Optional Cinderella days (see page A-7 for details)
Tracked Signals GPS/GLONASS, L1/L2 C/A and P-Code and Carrier,
WAAS/EGNOS
Table A-1. Receiver Specifications (Continued)
