Receiver Specifications
P/N 7010-0681
A-7
Cinderella days is an option that turns a single frequency, GPS
receiver into a dual-frequency, GPS+GLONASS receiver for 24 hours
every other Tuesday at GPS midnight. Refer to Topcon’s website for
more information and specific Cinderella day dates.
Tracking Functions
Multi-path
reduction
Code and Carrier
PLL/DLL setting Bandwidth, order, adjustable
Co-op tracking loop
setting
On/Off, Static Mode, Bandwidth of individual PLL,
Bandwidth of common PLL
Smoothing interval Code and Carrier
WAAS/EGNOS WAAS optional
EGNOS optional
Data Features
Formats TPS, NMEA, RTCM, BINEX
Features Up to 20 Hz update rate for real time position and raw
data (code and carrier)
10cm code phase and 0.1mm carrier phase precision
RTCM SC104 version 2.1, 2.2, 2.3, and 3.0 I/O
Multiple Base RTCM
Geoid and Magnetic Variation models
RAIM
Different DATUMs support
Output of grid coordinates
CMR and CMR+ support
Memory
Internal Memory Compact flash card (not removable)
Capacity Standard – 0 MB
Max – 1 GB
Logging Time 53 hours (8 MB, 15sec, L1/L2, 7 satellites)
Logging Interval 0.05 to 86400 seconds, depending on purchased options
Table A-2. GPS Board Specifications (Continued)
