Topcon HiPer Pro - Modem LED; Information Modes; Normal; Extended Information Mode (EIM)

Operation
HiPer Pro Operator’s Manual
4-8
Modem LED
The color of the TX/RX modem LED indicates if the modem has
power, is receiving signals, or is turned off.
For the Base TX/RX LED:
• No light – the modem is off
• Green flashes – the modem is in receiver mode
• Red flashes – the modem is in program mode
• Solid Green – a radio link has been established; the modem is in
receiver mode
• Green flashes once a second – a radio link has been established;
the radio is in transmit mode
For the Rover TX LED:
• No light – the modem is off
• Green flashes – the modem is in transmit mode
• Solid Red – the radio is transmitting
Information Modes
The receiver has two information modes: Normal and Extended
Information Mode (EIM).
Normal
In normal mode, the STAT LED indicates the number of tracked
satellites and the position’s computation status.
Extended Information Mode (EIM)
Extended Information Mode (EIM) is used for receiver testing
purposes. In this mode, the receiver continues to work as usual, but
the STAT LED indicates “extended” information using a
The Delimiter is a distinguishable double-blink that shows the overall
status of tests performed in EIM. The LED color for delimiter is
