Powering the Receiver
P/N 7010-0681
2-3
turned off or on. See “Power Management” on page 2-5 for more
information.
The Li-Ion batteries used in the receiver should run at no less than
98% capacity after 500 charging cycles. These batteries do not need
to be drained before recharging.
External Batteries
In addition to the internal batteries, you can use your receiver with
external batteries (Figure 2-1 on page 2-4). External batteries allows
you to continue using the receiver in case the internal batteries are
discharged and requires the following:
• a 12 V, 2.3 A*h battery
• a 2.3 A*h battery clip-to-SAE cable
• an SAE-to-Power Plug cable
NOTICE
NOTICE
When the receiver uses external batteries, set the charger
mode to Off. Otherwise, the external batteries will also
charge the internal batteries, causing operation time to
decrease. See “Power Management” on page 2-5 for more
information on setting the charger mode.
1. Connect the SAE ends of the battery clip-to-SAE and the SAE-to-
power plug cables.
2. Plug the power cable into the receiver’s power port.
3. Attach the battery clip to the battery.
