– Port C used internally to connect the modem and receiver
boards.
– Port D used for communication between the receiver and an
external device.
• USB – used for high-speed data transfer and communication
between the receiver and an external device.
• PWR – The power input port to which an external power source
(+6 to +28 V DC) is connected and where the unit is charged.
• Slant height measure mark (SHMM).
Figure 1-5. HiPer Pro Front Panel
MINTER
Reset Power
ADCBUSB
Slant Height Measure Mark
