Connector Specifications
66
P/N: 1011907-01
Specifications
Power Adapter Connector
Figure 71: Power Adapter Cable
Table 13 provides pin out specifications for the power adapter connector of the optional power adapter cable.
Table 13. Power Adapter Connector
Specifications
No.
RS232
Signal
A PWR_IN
B GND_IN
C IGN
