11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 101 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
11.20 BLADE TENSIONING KIT PARTS LIST
ID Description Quantity
1 Screw, Hex Head, 5/16" × 18 - 1-1/2" 2
2 Washer, 5/16" 18 × 2T 2
3 Screw, Set, 5/16" × 18 - 3/4" 1
4 Sliding Base 1
5 Blade-Wheel's Base 1
6 Pin, Spring, Slotted 4 × 20 1
7 Pin 1
8 Screw, Hex Head, 5/16" × 18 - 3/4" 4
9 Washer, Spring, 5/16" 4
10 Sliding Guide 2
11 Screw, Tension, 3/8 × 16 - 225 1
12 Spring, Compressed 1
13 Spacer Ring, 30 × 15L 1
14 Tension Gage (PN52673) 1
15 Tension Handle Hub 1
16 Handle 3
17 Spacer 1
