2: ABOUT YOUR MACHINE
©Tormach® 2024
Specifications subject to change without notice.
Page 14 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version 0324A)
For the most recent version, see tormach.com/support
2.1 MACHINE SPECIFICATIONS
Programmable Automatic Workpiece Positioning
Cut Lengths 0.157 in. to 50 in. (4 mm to 1270 mm)
Maximum Length Per Stroke Up to 10 in. (254 mm)
Maximum Strokes per Part 5
Maximum Parts per Program 999
Maximum Capacity
Rectangular Stock 6 in. tall × 8 in. wide (152 mm tall × 203 mm wide)
Round Stock 7 in. (178 mm) diameter
Material Weight 250 lbs (113 kg), subject to air supply pressure
Blade
Motor Power 1 hp (0.75 kW)
Blade Speeds 60 Hz:90, 134, 195, 255 ft/min (27, 41, 59, 78 m/min)
50 Hz: 70, 110, 160, 210 ft/min (22, 34, 49, 64 m/min)
Blade Length 93 in. (2362 mm)
Blade Width 0.75 in. (19 mm)
Blade Thickness 0.035 in. (0.9 mm)
Coolant
Capacity 2.65 gal (10 L)
Dimensions
Floor-To-Table Height 22 in. (559 mm)
Typical System Weight 450 lb (205 kg)
Power and Air Requirements
Primary Power Single-Phase 115 Vac, 50/60 Hz
Required Circuit Amperage Dedicated 15 A breaker
Compressed Air Source 90 psi to 120 psi (620 kPa to 827 kPa)
Space Requirements
Minimum Depth 36 in. (0.91 m) plus the length of stock
Minimum Height 67 in. (1.71 m)
Minimum Width 60 in. (1.53 m)
