Tormach AF50+ - Sliding Blade Guide (Parent) Parts List

11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 97 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
11.16 SLIDING BLADE GUIDE (PARENT) PARTS LIST
ID Description Quantity
1 Retaining Ring (PN52669) 2
2 Bearing (PN52667) 5
3 Eccentric Shaft (PN52662) 1
4 Center Shaft (PN52663) 1
5 Adjustable Blade Guide (PN52664) 1
7 Screw, Flat Head, 1/4" × 20 - 1/2" 2
8 Screw, Round Head, 5/16" × 18 - 1-1/4" 1
9 Washer, Spring, 5/16" 1
10 Washer, 5/16" 18 × 2T 1
11 Nut, 3/8" - 24 2
12 Washer, Spring, 3/8" 2
13 Sliding Blade Guide (PN 52665) 1
14 Shaft (PN 52666) 1
15 Blade Cover 1
