11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 86 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version 0324A)
For the most recent version, see tormach.com/support
11.6 INFEED TABLE PARTS LIST
ID Description Quantity
1 Nut, M12 1
2 Washer, 1/2" 28 × 3T 1
3 Bushing, D25x12L 1
4 Bushing, D34.5*d30.3*6.5T 1
5 Flow-Control Elbow 2
6 Infeed Air Cylinder – Body 1
7 Proximity Sensor 2
8 Screw, Socket Head Hex, 1/4" - 20 × 3/4" 5
9 Bracket 2
10 Infeed Air Cylinder Mount 1
11 Bumper 2
12 Acme Length Adjustment Screw, M12 × 3 - 369 mm 1
13 Washer, 3/8" 20 × 2T 1
14 Infeed Table Bracket 1
15 Bolt, Hex Head, 1/4" × 20 - 1" 1
16 Bracket 1
17 Nut, Hex, 1/4" 20 1
18 Bumper 1
19 Screw, Round Head, 3/16" × 24 - 3/8" 10
20 Acme Nut Body 1
21 Acme Screw Bracket 1
22 Screw, Hex Head, 1/4" × 20 - 1/2" (with spring washer) 2
23 Nut, 3/8" 16 4
24 Infeed Leveling Foot 1
25 Infeed Support Leg 1
26 Roller – Infeed Table 1
27 Infeed Table Bottom Cover 1
28 Guard Support – Left 1
29 Screw, Socket Head Hex, M5 × 35 1
30 Screw, Round Head, 1/4" × 20 - 1/2" 10
