Tormach AF50+ - Head Casting Parts List

11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 83 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
11.4 HEAD CASTING PARTS LIST
ID Description Quantity
1 Saw Head Casting 1
2 Idler Wheel (PN52644) 1
3 Drive Wheel (PN 52645) 1
4 Retaining Ring S25 1
5 Screw, Hex Head, 3/8" × 16 - 1-1/2" 7
6 Washer, Spring, 3/8" 4
8 Washer, 1/4" 16 × 1.5T 10
9 Screw, Binding Head, 3/16" - 3/8" 2
10 Wire Clamp, 5/8" 2
11 Washer 1
12 Support Arm (PN 52646) 1
13 Pacer Ring, 32 × 23 × 10.5 1
14 Screw, Hex Head, 5/16" × 18 - 1" 4
15 Plum Handle, 1/4" - 20 1
16 Belt Cover 1
17 Blade Cover 1
18 Saw Blade 1
19 Screw, Hex Head, 1/4" × 20 - 1/2" (with spring washer) 3
20 Chip Shelter 1
21 Motor Belt (PN 52647) 1
22 AF50+ Motor 1
23 Protective Cover (PN 52648) 1
24 Bracket – Clamp Pressure Regulator 1
25 Screw, Round Head, 1/4" × 20 - 1/2" 10
26 Washer, 5/16" 18 × 2T 2
27 Hydraulic Pivot Arm (PN52649) 1
28 Gear Box Assembly (PN52650) 1
29 Limit Switch (PN 52651) 1
30 Washer, 3/8" 16 × 3T 3
31 Brush (PN52652) 1
32 Brush Holder (PN52653) 1
