11.2 BASE CASTING PARTS LIST
ID Description Quantity
1 Base Casting 1
2 Hydraulic Cylinder (PN 52674) 1
3 Shaft (PN52675) 1
4 Outfeed Guide Return Tray 1
5 Outfeed Guide Side Panel 1
6 Outfeed Guide 1
7 Cover 1
8 Limit Stopper (Front) 1
9 Washer, 5/16" 18 × 2T 3
10 Screw, Hex Head, 5/16"× 18 - 3/4" 3
11 Screw, Hex Head, 1/4" × 20 -1/2" (with spring washer) 1
12 Washer, 1/4'' 16 × 5T 1
13 Shipping Bracket 1
14 Screw, Hex Head, 3/8" ×16 - 1-1/2" 1
16 Flat Key, 5 × 5 - 15 1
17 Hand Wheel 1
18 Washer, 1/2" 28 × 2T 1
19 Vise Lead Screw (PN52676) 1
20 Vise Lead Screw Nut (PN52677) 1
21 Clamp Block – Saw Table 1
22 Washer, 3/8" 20 × 2T 2
23 Screw, Round Head, 3/8" × 16 - 3-1/2" 2
24 Screw, Round Head, M6 - 55 4
25 Clamp Air Cylinder 1
26 Round Head Screw, 5/16" × 18 - 1-1/4" 2
27 Infeed Moveable Jaw (PN 52678) 1
28 Clamp Vise Washer 1
29 Clamp Vise T-Nut 1
30 Screw, Hex Head, 1/2" × 12 - 2" 1
31 Nut, 1/2" 12 1
