11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 81 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
ID Description Quantity
32 Washer, 1/2" 28 × 3T 2
33 Rear Fixed Jaw 1
34 Screw, Square Head, 1/2" × 12 -2" 1
35 Screw, Round Head, 3/16" × 24 - 3/8" 8
36 Angle Scale 1
37 Nut, 3/8" 16 3
38 Washer, 3/8"23 × 2T 1
39 Spring Bracket 1
40 Adjustable Spring Rod (PN52679) 1
41 Balancing Spring (PN 52680) 1
42 Screw, Hex Head, 3/8" × 16 - 1-3/4" 1
43 Limit Stopper (PN 52681) 1
44 Screw, Hex Head, 5/16" × 18 - 1/4" 2
45 Washer, Spring, 5/16" 2
46 Connector, 1/2" 1
47 Motion Guard Lid 1
48 Bracket – Nitrogen Shock 1
49 Gas Spring 1
50 Screw, Round Head, 1/4" × 20 - 1/2" 8
51 Proximity Switch Cover 1
52 Proximity Sensor Switch (PN52682) 1
53 Fitting 1
54 Silencer 1
