9.1 MACHINE SAFETY
Before operating the machine in any way, you must
read and understand this section.
Safe operation of the machine depends on its proper use and
the precautions you take. Only trained personnel — with a
clear and thorough understanding of its operation and safety
requirements — shall operate this machine.
9.2 MAINTENANCE SCHEDULES
To keep your machine running as smoothly as possible, you
must regularly do the following maintenance procedures.
Note: Before you begin any maintenance procedures,
read and understand Maintenance Safety.
If you disassemble any components, refer to the machine's
reference drawings when you've completed the maintenance
procedure. For information, see "Diagrams and Parts Lists"
(page77). For any additional support, we can help. Create a
support ticket with Tormach Technical Support at
tormach.com/how-to-submit-a-support-ticket for guidance on
how to proceed.
9.2.1 Daily
Clean the blade brush of swarf.
Clean the drip pan of swarf.
Examine the drip pan grate for clogs.
Examine the coolant level and condition.
Use a rust inhibitor on all exposed, non-lubricated, non-
painted metal surfaces.
Note: Don't use rust inhibitor on the guide rails
or vice lead screw.
Verify that the FRLFilter-Regulator-Lubricator has at
least 90 psi compressed air, and that the lubricator has
air tool oil above the bottom of the plastic tube.
Apply oil (like E-900 ball screw lubricant, or similar) to
the linear rails.
9.2.2 Weekly
Clean all exterior surfaces with a clean rag.
Examine the blade brush and adjust it if it's not in
contact with the blade.
9.2.3 Monthly
Clean the electrical cabinet of dust with a clean cloth or
compressed air.
Put #2 tube grease on each guide rail within the travel
path of the infeed table.
Clean fine swarf from the coolant tank.
9.2.4 Semi-Annually
Note: After the first 90 days of operation, complete
the items on this list. After that, complete the items
every six months.
Examine the motor belt for wear.
Lightly lubricate the vise lead screw with #2 tube grease.
9.2.5 Annually
Inspect the gearbox for leaks.
9.3 REPLACE THE GEARBOX OIL
1. Power off the bandsaw and disconnect it from the main
air supply.
a. Push the Emergency Stop button on the operator
panel to lock it into the disabled position.
b. Turn the Main Disconnect switch to OFF.
Mains power is disconnected from the machine.
c. Disconnect the air line from your site from the input
port on the FRLFilter-Regulator-Lubricator.
2. Put a catch pan for the gear oil below the gearbox drain
plug.
3. Remove the four bolts from the gear box, and set aside
the cover plate and gasket.
4. Remove the drain plug and allow the oil to drain out.
5. Remove the remaining oil with a rag.
6. Install the drain plug and fill the gearbox with
approximately 10 oz (0.3 liters) of SAE 90 Gear Oil (ISO
220).
©Tormach® 2024
Specifications subject to change without notice.
Page 46 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version 0324A)
For the most recent version, see tormach.com/support
9: MACHINE MAINTENANCE
