11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 103 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
11.22 LIFT CYLINDER ASSEMBLY PARTS LIST
ID Description Quantity
1 Lift Cylinder 1
2 Lift Cylinder Bracket 1
3 Washer, 3/8" 20 × 2T 2
4 Screw, Hex Head, 3/8" × 16 - 1"L 2
5 Lift Cylinder Axle 1
6 Nut, 3/8" - 16 2
7 Bottom Pivot 1
8 Flow-Control Elbow 1
9 Muffler 1
10 Lift Cylinder Stop Base 1
11 Length Adjustment Screw 1
12 Acme Nut Insert 1
13 Spring 15 × 12 1
14 Acme Nut Body 1
15 Screw, Socket Head Hex, 3/8" × 16 - 2-1/2" 1
16 Clevis Lift Cylinder 1
17 Screw, Socket Head Hex, 1/4"× 20 - 3/4" 2
18 Top Pivot Mount 1
19 Lift Cylinder Stop 1
20 Proximity Sensor 1
21 Pull Ring 1
22 Protective Cover 1
