11.14 GEAR BOX ASSEMBLY PARTS LIST
ID Description Quantity
1 Screw, Hex Head, 1/4" × 20 - 1/2" (with spring washer) 4
2 Screw, Hex Head, M8 × 1 1
3 Cover 1
4 Gasket 1
5 Gear Box Housing 1
6 Screw, Set, 5/16" × 18 - 3/8" 1
7 Worm Shaft 1
8 Bearing 2
9 Bushing 1
10 Retaining Ring 1
11 Key, Flat, 5 × 5 - 30 1
12 Screw, Set, 1/4" × 20 - 3/8" 2
13 Pulley 1
14 Screw, Round Head, 3/16" × 24 - 3/8" 3
15 Bearing Cover 1
16 Shaft 1
17 Key, Flat, 6 × 6 - 20 2
18 Retaining Ring 2
19 Spacer Ring 1
20 Bearing 2
21 Spacer Ring 1
22 Worm Gear 1
To Next Page
