11.12 MOTOR ASSEMBLY PARTS LIST
ID Description Quantity
1 Motor Bracket – Lower 1
2 Washer, 5/16" 18 × 2T 12
3 Screw, Hex Head, 5/16" × 18 - 3/4" 4
4 Screw, Hex Head, 5/16" × 18 - 1" 4
5 Motor Bracket – Upper 1
6 Motor (PN52660) 1
7 Key, Flat, 5 × 5 - 30
8 Motor Pulley 1
9 Screw, Set, 1/4"× 20 - 1/2" 2
10 Nut, 5/16" -18 6
11 Screw, Truss Head, 5/16" × 18 - 1" 4
12 Screw, Round Head, 1/4" × 20 - 1/2" 1
13 Washer, 1/4" 16 × 1.5T 1
To Next Page
