11.18 SLIDING BLADE GUIDE (PARENT) PARTS LIST
ID Description Quantity
1 Bearing 5
2 Center Shaft 1
3 Retaining Ring 2
4 Egocentric Shaft 1
5 Screw, Truss Head, 5/32" × 32 - 1/2" 2
6 Blade Guard (PN52670) 1
7 Sliding Blade Guide (PN52671) 1
8 Adjustable Blade Guide (PN52672) 1
9 Nut, 3/8" - 24 2
10 Washer, Spring, 3/8" 2
11 Washer, Spring, 5/16" 1
12 Screw, Round Head, 5/16" × 18 - 1-1/4" 1
13 Shaft 1
To Next Page
