11.24 COOLANT SYSTEM PARTS LIST
ID Description Quantity
1 Coolant Tank, 13 Liter 1
2 PVC Hose, 6 × 1200 1
3 Coolant Pump (PN52693) 1
5 Quick-Fitting (L-Shaped), 3/8" × 8 (PN 52690) 1
6 Screw, Truss Head, 1/4"× 20 - 1/2" 2
7 Nozzle 12
8 Nozzle Support (PN52692) 1
9 Screw, Set, 1/4" × 20 - 1/2" 1
10 Valve, 1/8" × 1/8" (Female) (PN52691) 2
11 Fitting, 6 × 1/8 (Male) 2
12 PVC Hose, 4 × 1600 1
13 PVC Hose, 4 × 730 (PN 52697) 1
14 Pneumatic Fitting 1
16 Nozzle 1
17 Blade Cover 1
18 Nut, 5/16" - 18 1
19 PVC Hose, 5/8" × 260 (PN52694) 1
