11.8 STAND PARTS LIST
ID Description Quantity
1 Shaft (PN52687) 1
2 Wheel (PN52688) 2
3 Washer, 5/8"30 × 3T 4
4 Split Pin, 3 × 25 2
5 Right Stand Panel 1
6 Middle Stand Panel 1
7 Nut, 3/8" - 16 9
8 Washer, 3/8" 23 × 2T 10
9 Screw, Hex Head, 3/8" 16 × 1" 9
10 Leveling Foot (PN52683) 2
11 Cover Panel 1
12 Left Stand Panel 1
13 Nut, 5/16" - 18 6
14 Washer, 5/16" 18 × 2T 8
15 Screw, Hex Head, 5/16" × 18 - 1-1/2" 4
16 Handle 1
17 Screw, Hex Head, 5/16"× 18 - 3/4" 1
18 Filter (PN52689) 1
19 Pipeline 1
20 Water Pan 1
21 AF50+ Logo Decal 1
22 Screw, Round Head, 1/4" × 20 - 1" 2
23 Air Fixed Board 1
24 Electrical Cabinet 1
25 Electrical Cabinet Cover 1
