1. Identify the blade brush.
Figure 10-11: Blade brush.
2. Adjust the blade brush until its bristles overlap the blade.
If the Blade Brush (PN38033) is worn or damaged, you must replace it.
10.3.4 Adjust the Height of the Infeed Table
1. Find a piece of 24 in. stock. We recommend using one of the following:
l Cold-rolled steel (that's at least 1 in. square)
l Extruded aluminum (that's at least 1-1/2 in. square)
l Structural tubing (that's at least 1-1/2 in. square)
2. Move the infeed table so that it's approximately in the center of travel.
3. Loosen three M10 socket head cap screws on the base casting. This allows you to adjust the height of the infeed table.
Figure 10-12: M10 socket head cap screws on the base casting.
4. Open the clamps on both vises with the handwheel and the clamp handle. Then, load the stock between the vises as shown in the
following image.
Figure 10-13: Stock loaded between the vises.
