11: DIAGRAMS AND PARTS LISTS
©Tormach® 2024
Specifications subject to change without notice.
Page 87 UM10825: AF50+ Autofeed Bandsaw Operator's Manual (Version
0324A)
For the most recent version, see tormach.com/support
ID Description Quantity
31 Washer, 1/4" 16 × 1.5T 2
32 Guard Support - Right 1
33 Scale Mounting Bracket – Outboard 1
34 Bolt, Hex Head, M10 × 25 2
35 Scale Mounting Bracket – Inboard 1
36 Indicator 35x26x1.0T 1
37 Infeed Table 1
38 Clamp Jaw T-Nut 1
39 Scale 1
40 Screw, Flat Head, 5/32" × 32 - 3/8" 2
41 Clamp Block T-Nut 1
42 60 mm Air Cylinder 1
43 Clamp Block – Infeed Table (PN52685) 1
44 Screw, Socket Head Hex, M6 × 55 4
45 Top Plate - Clamp Block 1
46 Nut, M5 2
47 Screw, Socket Head Hex, 5/16" × 18 - 3-1/2" 2
48 Clamp Handle, M8 × 1.25 (PN52686) 1
49 Silencer 1
50 Elbow Fitting 1
51 Screw, Socket Head Hex, 5/16" × 18 - 1/2" 2
52 Infeed Movable Jaw 1
53 Bolt, Hex Head, 5/16" × 18 - 1/4" 4
54 Washer, 5/16" 18 × 2T 4
55 Infeed Fixed Vise Jaw 1
56 Washer, 3/8" 20 × 2T 3
57 Bolt, Hex Head, 3/8" × 16 - 1-1/4" 3
58 Infeed Guide Rail 1
59 Infeed Roller Spacer Plate 2
60 Roller Bracket 2
62 Washer, 1/4'' 16 × 1.5T 2
63 Screw, Hex Head Socket, 5/16" × 18 - 1" 7
