Toro Groundsmaster 3320-D Service Manual

HydraulicTestFittingKit
ToroPartNo.TOR4079
ThiskitincludesavarietyofO-ringfacesealttingstoletyouconnectthetestgaugesintothesystem.
FITTINGTYPESIZE
PARTNUMBER
4ORFS(9/16–18)TOR4079–3
6ORFS(11/16–16)TOR4079–12
8ORFS(13–16–16)TOR4079–4
Swivelnutruntee(2each)
10ORFS(1–14)TOR4079–5
4ORFS(9/16–18)TOR4079–13
6ORFS(11/16–16)TOR4079–14
8ORFS(13–16–16)TOR4079–15
Plug(2each)
10ORFS(1–14)TOR4079–16
4ORFS(9/16–18)TOR4079–17
6ORFS(11/16–16)TOR4079–18
8ORFS(13–16–16)TOR4079–19
Cap(2each)
10ORFS(1–14)TOR4079–20
6ORFS(11/16–16)to
8SAE-ORB(3/4–16)
TOR4079–8
8ORFS(13–16–16)to
8SAE-ORB(3/4–16)
TOR4079–9
Union(1each)
10ORFS(1–14)to
8SAE-ORB(3/4–16)
TOR4079–2
10ORFS(1–14)to
8SAE-ORB(3/4–16)
TOR4079–7
Reducer(1each)
12ORFS(13/16–12)to
8SAE-ORB(3/4–16)
TOR4079–6
4ORFS(9/16–18)TOR4079–10
6ORFS(11/16–16)TOR4079–11
8ORFS(13/16–16)TOR4079–21
Testconnector–Femalethread(2each)
10ORFS(1–14)TOR4079–1
4SAE-ORB(7/16–20)TOR4079–22
Testconnector–Malethread(2each)
1/8NPTFTOR4079–23
Groundsmaster
®
3280-D/3320
Page5–41
HydraulicSystem:SpecialTools
05138SLRevB
