FuelPump(Groundsmaster3280-D)
g225173
Figure170
1.Fuelhose(fromtank)3.Fuelhose(fromengine)5.Inlettting
2.Fuelpump4.Pumpdischargehose
6.Fuel/waterseparator
g230997
Figure171
1.Fuelhose(fromtank)
4.Pumpdischargehose
7.Fuel/waterlter
2.Fuellter5.Fuelhose(toengine)
3.Fuelpump
6.Inlettting
ThefuelpumpusedontheGroundsmaster3280-D(forModels30344and
30345)isattachedtothesupportbracketinsidetherightsideframenearthe
fuel/waterseparator(Figure170).ThefuelpumpusedontheGroundsmaster
3280-D(exceptModels30344and30345)isattachedtothesupportbracket
insidetherightsideframenearthefuel/waterlter(Figure171).
IMPORTANT
Whentestingthefuelpump,ensurethatthepumpisnotoperated
withoutfuel.
ElectricalSystem:TestingtheElectricalComponents
Page6–70
Groundsmaster
®
3280-D/3320
05138SLRevB
