Toro Groundsmaster 3320-D Service Manual

g221829
Figure1
ServiceProcedureIcons
ThefollowingiconsappearthroughoutthisServiceManualtobringattentionto
specicimportantdetailsofaserviceprocedure.
CriticalProcess
Thisiconisusedtohighlight:
•installingsafetyequipment(shields,guards,seatbelts,brakesandR.O.P .S.
components)thatmayhavebeenremoved
•dimensionsorsettingsthatmustbemaintainedforpropermachineoperation
•aspecicfastenertighteningsequence
•componentorientationthatmaynotbeobvious
CriticalTorque
Thisiconisusedtohighlightanassemblytorquerequirementthatisdifferent
thanwhatisrecommendedintheStandardT orqueTables;refertoTorque
Specications(page2–5).
FluidSpecications
Thisiconisusedtohighlightuidspecicationsandcapacitiesthatareless
common,andmaynotappearonthemachineservicedecalorinthemachine
Operator’sManual.
Note:RefertotheservicedecalonthemachineandthemachineOperator’s
Manualforcommonlyuseduidspecicationsandcapacities.
Preface
Page6
Groundsmaster
®
3280-D/3320
05138SLRevB
