TOUCH SCREEN CONTROLLER for Air Conditioning Control System Owner's Manual
4-8. Monitor screen
Tapping the [Monitor] icon in the display switching icon area opens the Monitor screen. You can check the operating status of
many air conditioners in a single screen. It is also possible to change the status of air conditioners.
[1] Changing the settings of air conditioners on the Monitor screen
(1) Tap the unit icon group <1> that you want to set.
All the levels to which that unit belongs are highlighted.
(2) Change the air conditioner settings in the same way as "4-2.Changing air conditioner settings" from the "Air conditioner
status list"
<2>.
<1><1>
<2><2>
[Monitor screen]
Unit icon area
Shows the status of air conditioners.
: Indicates it is operating (red or green).
: Indicates it is not operating (grey).
: Indicates an alarm has occurred.
