TOUCH SCREEN CONTROLLER for Air Conditioning Control System Owner's Manual
[4] Displaying graphs of other dates
▼ Display graphs of other dates by using the arrow button
(1) Tapping the arrow button
<1> displays the graph of another date. The units that can be changed are as follows.
Indoor unit graph by the day: moves the graph by daily units.
Indoor unit graph by the month: moves the graph by monthly units.
▼ Display graphs of other dates by using the calendar
(1) Tap [Day]
<2>.
The calendar appears.
(2) Select the day or month from the calendar <3>. The units that can be selected are as follows.
Indoor unit graph by the day: can be selected by daily units.
Indoor unit graph by the month: can be selected by monthly units.
(3) Tapping the [OK] button
<4> displays the graph for the selected day or month.
* You can display graphs for every 2 years.
<1>
<2>
<3>
<4>
[Indoor unit graph by day screen]
[Calendar screen]
To Next Page
