4 Replacement Procedures 4.3 HDD
4-14 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Installing the HDD
The following describes the procedure for installing the HDD (See Figure 4-4, 4-5 and 4-6).
1. Install the HDD to the HDD holder and secure them with the following screws.
? M3?4S FLAT BIND x4
NOTE: 1. Although they are 3mm head screws, screw torque must be set in
0.284 N?m (2.9?0.4 kgf ?cm) for four screws securing the HDD holder.
2. Tighten the screw in the order of (1) and (2).
2. Insert the HDD assembly into the HDD slot and slide it carefully to the connector
CN1800 on the system board.
3. Install the HDD slot cover and secure it with the following screw.
? M2.5?4B FLAT BIND x1
To Next Page
