Toshiba QOSMIO F20

4 Replacement Procedures 4.6 Keyboard
4-20 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
5. Remove the following screws fixing the keyboard support plate.
? M2.5?6B FLAT BIND screw x1
6. Remove the keyboard support plate.
Figure 4-11 Removing the keyboard support plate
7. Disconnect the keyboard flexible cable from the connector CN3200 on the system
board.
8. Remove the keyboard.
CN3200
M2.5?6B FLAT BIND
Keyboard support plate
Keyboard flexible cable
Keyboard
