4 Replacement Procedures 4.8 Display assembly
4-30 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
11. Install the LCD cable holder with the following screw.
? M2.5?4B FLAT BIND x1
12. Stick four insulators and a glass tape to fix cables.
13. Close the display, turn the computer upside down and secure the display assembly
with the following screws.
? M2.5?12B FLAT BIND screw x9 (“12” in the figure)
? M2.5?6B FLAT BIND screw x7 (“6” in the figure)
? M2.5?4B FLAT BIND screw x4 (“4” in the figure)
NOTE: Be sure to apply lock tight to the screws with the mark of lock tight on it.
14. Connect the USB board cable to the connector CN4611 and the speaker cable to the
connector CN6170 on the system board.
To Next Page
