4 Replacement Procedures 4.18 USB board/Speaker
4-52 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Installing the USB board/Speaker
The following describes the procedure for installing the USB board/Speaker (See Figure 4-37
to 4-39).
1. Install the Cable holder (R) on the base assembly and secure it with the following
screws.
? M2.5?6S TAPPING x2
2. Install the Speaker (R) on the slot of the base assembly and pass the Speaker (R)
cable thought the guide of Cable holder (R) and the guide of base assembly.
3. Install the Speaker (L) in the slot of the base assembly.
4. Pass the Speaker cable (L) and USB board cable through the guide of base assembly.
5. Install the Cable holder (L) with the following screw.
? M2.5?6S TAPPING x1
6. Pass the USB board cable above the Cable holder (L) and secure the USB board with
the following screw.
? M2.5?6S TAPPING x1
To Next Page
