4 Replacement Procedures 4.20 LCD unit/FL inverter
4-60 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
8. With the bottom edge of the LCD unit on the display cover, lift only the top edge of
the LCD unit. After peeling off the aluminum tape, disconnect the LCD cable from
the connector on the back of the LCD unit. Remove the LCD unit.
Figure 4-46 Removing the LCD unit
LCD cable
Aluminum tape
