4.20 LCD unit/FL inverter 4 Replacement Procedures
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] 4-59
7. Remove the following screws fixing the LCD unit.
? M2?6S BIND x4
Figure 4-45 Removing the screws
M2x6S BIND
