Toshiba QOSMIO F20

4 Replacement Procedures 4.24 Fluorescent lamp
4-76 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
4. Unlatch the hooks on the bottom first and then the hooks on the right and left sides to
remove the top chassis from the mold frame.
Figure 4-60 Replacing Samsung fluorescent lamp (W-XGA 1-lamp) (4)
Top chassis
Mold frame
Hook
