Toshiba QOSMIO F20

Appendices Appendix C Pin Assignments
C-34 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Table C-35 PCI-EX I/F connector (230-pin)(3/4)
PIN No. Signal name I/O PIN No. Signal name I/O
121 PEGC04-P1N O 122 PECG04-P1N I
123 PEGC04-P1P O 124 PECG04-P1P I
125 GND - 126 GND -
127 PEGC03-P1N O 128 PECG03-P1N I
129 PEGC03-P1P O 130 PECG03-P1P I
131 GND - 132 GND -
133 PEGC02-P1N O 134 PECG02-P1N I
135 PEGC02-P1P O 136 PECG02-P1P I
137 GND - 138 GND -
139 PEGC01-P1N O 140 PECG01-P1N I
141 PEGC01-P1P O 142 PECG01-P1P I
143 GND - 144 GND
145 PEGC00-P1N O 146 PECG00-P1N I
147 PEGC00-P1P O 148 PECG00-P1P I
149 GND - 150 GND
151 XPEPEG-P3N I 152 NVARED-PXP O
153 XPEPEG-P3P I 154 A-GND -
155 GND 156 NVAGRUN-
PXP
O
157 RSTVGA-P3N 158 A-GND -
159 (PDNVGA-
P3N)
- 160 NVABLU-PXP O
161 (DVIDET-S3N) - 162 A-GND -
163 GND 164 AHSYNC-P3P I/O
165 GND 166 AVSYNC-P3P I/O
167 (DVATX0-P3P) - 168 A-GND -
169 (DVATX0-P3N) - 170 (NVBRED-
PXP)
-
171 GND 172 A-GND -
173 (DVATX1-P3P) - 174 (NVBGRN-
PXP)
-
175 (DVATX1-P3N) - 176 A-GND -
177 GND - 178 (NVBBLU) -
