Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-35
Table C-35 PCI-EX I/F connector (230-pin) (4/4)
PIN No. Signal name I/O PIN No. Signal name I/O
179 (DVATX2-P3P) - 180 GND -
181 (DVATX2-P3N) - 182 TSDA-P3P I/O
183 GND 184 TSCL-P3P I/O
185 (DVACK-P3P) - 186 GALERT-P3P O
187 (DVACK-P3N) - 188 GTHERM-P3P O
189 GND 190 GPUHOT-S5V I
191 NVASCL-P3P I/O 192 GND -
193 NVASDA-P3P I/O 194 (SVSCL-P3P) -
195 (NVBSCL-P3P) 196 (SVSDA-P3P) -
197 (NVBSDA-P3P) 198 (SVRST-S3N) -
199 NVCSCL-P3P I/O 200 (VDMDD-S3P) -
201 NVCSDA-P3P I/O 202 (SVRXPD-
S3N)
-
203 GND - 204 (SVTXPC-
S3N)
-
205 LCDVEN-P3P O 206 A-GND -
207 FLVEN-P3P O 208 (COMP-IN) -
209 GND - 210 A-GND -
211 GPON-E3P I 212 (LUMA-IN) -
213 VG1R8-P1V O 214 A-GND -
215 PVON-S5P O 216 (CROM-IN) -
217 10-EAV - 218 (P3V) -
219 (ID2) - 220 (P3V) -
221 E5V - 222 P3V -
223 (ID1) - 224 P3V -
225 M5V - 226 P3V -
227 (ID0) - 228 P3V -
229 P5V - 230 P3V -
To Next Page
