Toshiba TECRA A9 Series Maintenace Manual

3.20 ONLY ONE TEST 3 Tests and Diagnostics
3.20.5 Subtest 5 LED
This subtest checks if each LED lights properly.
The following message appears in the display in order. Follow the instructions
in the display to execute the test.
[HDD Access LED test]
Press any key and following message appears in the display.
[Caps/Num/Overlay BT/W-LAN LED test]
(1) Press [Caps Lock ] key ! ...Caps (on/off)
(2) Press [Fn + F10 ] key ! ...Arrow (on/off)
(3) Press [Fn + F11 ] key ! ...Num (on/off)
(4) Slide [BT/W-LAN switch L&R]! (on/off)
Confirm corresponding LED lights properly.
Press Enter and following message appears in the display.
Check [DC-IN]&[Power]&[Main Battery]LED= Green
Check if the color of the message changes orange to green alternately.
Press Enter and return to the ONLY ONE TEST menu.
3.20.6 Subtest 6 Buuton
This subtest checks the moving of the of the front operation panel button.
Press the Toshiba Assist button after the following message appears.
Step 1 X 1 2
* * *.
Press Function button (Assist button )
OK message appears in the display if the test ends without an error.
Press any key return to each Steps if NG! or Press any key message apprears.
TECRA A9(S5/P5/S200) Maintenance Manual (960-633) [CONFIDENTIAL] 3-45

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
