Toshiba TECRA A9 Series Maintenace Manual

4 Replacement Procedures 4.32 Fluorescent Lamp
4.32.1 Replacing the 15.4-inch WXGA Samsung Fluorescent Lamp
To replace the 15.4-inch WXGA Samsung fluorescent lamp, follow the steps below and refer
to figures 4-58 to 4-61.
Removing the fluorescent lamp
1. Remove the PCB cover.
CAUTION: Handle with care not to damage COF of S/D ICs.
PCB cover
Figure 4-58 Replacing Samsung fluorescent lamp (WXGA) (1)
4-100 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
