3 Tests and Diagnostics 3.22 Log Utilities
3.22.2 Operations
1. Select 5 and press Enter in the DIAGNOSTIC MENU, the error information is
displayed in the following format:
XXXXX ERRORS
CNT TS-NO PASS STS ADDR WD RD HSTS [ERROR STATUS NAME]
001 FDD 02 0000 103 00001 00 00 0000 FDD-WRITE PROTECTED
001 FDD 01 0000 180 00001 00 00 0000 FDD-TIME OUT ERROR
Error count
Pass count
Error status
Address
Subtest number
Test name
Error status name
Read data
Write data
HDC status
[[1:Next,2:Prev,3:Exit,4:Clear,5:Print,6:FD Log Read,7:FD Log Write]]
2. The error information displayed on the screen can be manipulated by the following
number keys:
The 1 key scrolls the display to the next page.
The 2 key scrolls the display to the previous page.
The 3 key returns to the Diagnostic Menu.
The 4 key erases all error log information in RAM.
The 5 key outputs the error log information to a printer.
The 6 key reads the log information from a floppy disk.
The 7 key writes the log information to a floppy disk.
3. In the case of “error retry OK”, a capital “R” will be placed at the beginning of the
error status. However, it is not added to the error count.
3-52 [CONFIDENTIAL] TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
