Appendix C Pin Assignments Appendices
TECRA A9(S5/P5/S200) Maintenance Manual (960-633)[CONFIDENTIAL] C-17
C.12 CN3240 Dual Point interface connector (8-pin)
Table C-12 Dual Point interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 SP-P5V - 2 SPX-PXP O
3 SPY-PXP O 4 SP-GND -
5 GND - 6 IPDCLK-P5P I/O
7 IPDDAT-P5P I/O 8 P5V I
1T GND - 2T GND -
C.13 CN3490 Debug Port interface connector (8-pin)
Table C-13 Debug Port interface connector (8-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 SP-P5V - 2 SPX-PXP O
3 SPY-PXP O 4 SP-GND -
5 GND - 6 IPDCLK-P5P I/O
7 IPDDAT-P5P I/O 8 P5V I
1T GND - 2T GND -
C.14 CN4100 LAN interface connector (14-pin)
Table C-14 LAN interface connector (14-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1
ACT-E3N O
2
LINK-E3N O
3
LNP-E3V I
4
LNP-E3V I
5 6
7
ZBIDCN-EXN I/O
8
ZBIDDP-EXP I/O
9
ZBIDCN-EXN I/O
10
ZBIDCP-EXP I/O
11
ZBIDAP-EXP I/O
12
ZBIDAN-EXN I/O
13
ZBIDBP-EXP I/O
14
ZBIDBN-EXN I/O
