Appendices Appendix C Pin Assignments
C-20 [CONFIDENTIAL]TECRA A9(S5/P5/S200) Maintenance Manual (960-633)
C.20 CN5000 LCD interface connector (40-pin)
Table C-20 LCD interface connector (40-pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 FL-P5V I 2 FL-P5V I
3 FL-P5V I 4 NC -
5 GND - 6 GND -
7 GND - 8 (BRT2DA-S3P) -
9 (BRT10-P5P) - 10 (BRT0) -
11 GND - 12 PNL-P3V I
13 PNL-P3V I 14 P3V I
15
TSCL-P3P I/O
16
TSDA-P3P I/O
17
ZTXDA0-PYN I
18
ZTXDA0-PYP I
19
GND -
20
ZTXDA1-PYN I
21
ZTXDA1-PYP I
22
GND -
23
ZTXDA2-PYN I
24
ZTXDA2-PYP I
25
GND -
26
XTXCKA-PYN I
27
XTXCKA-PYP
28
GND -
29
ZTXDB0-PYN I
30
ZTXDB0-PYP I
31 GND - 32 ZTXDB1-PYN I
33 ZTXDB1-PYP I 34 GND -
35 ZTXDB2-PYN I
36
ZTXDB2-PYP I
37 GND -
38
XTXCKB-PYN I
39 XTXCKB-PYP I
40
GND -
1T GND -
2T
GND -
3T GND -
4T
GND -
5T GND -
6T
GND -
