4 Replacement Procedures 4.8 Keyboard
4.8 Keyboard
Removing the Keyboard
To remove the keyboard, follow the steps below and refer to Figure 4-10 to 4-12.
1. Turn over the computer.
2. Open the display and make it flat.
3. Insert your fingers into the slots on both sides and remove the keyboard holder.
Keyboard holder
Slot
Slot
Display
Figure 4-10 Removing the keyboard holder
4-20 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)
